Large Image :  Cable Pulling Device | RUIWOR

Product Details:
Place of Origin: JIANGXI, CHINA.
Brand Name: RUIWOR
Model Number: RW0500~5600
Payment & Shipping Terms:
Minimum Order Quantity: 50 Pieces, Sample order less than MOQ is acceptable.
Price: US $0.8 - 2.6 / Piece
Packaging Details: 50pcs or 100pcs per opp bag, bag size: 25*30CM, carton size: 43* 21* 27cm
Delivery Time: 1-15 work days
Payment Terms: T/T, Western Union, MoneyGram, Paypal (PayPal accout is info@ruiwor.com)
Supply Ability: 80000 Pieces per Week, Production capacity can raise for urgent order.
Detailed Product Description
Key Word: Cable Pulling Device Cable Length: 5 - 400CM For Options
Cable Diameter: 0.45 -2.0MM For Options Retracting Forces: 0.1LB - 3LB For Options
Box Size: Smallest Is 25*25*8.3MM, Biggest Is 63.4*63.4*17.5MM Box Shape: Round,Square,Cuboid,D-shaped, Drop-shaped,Heart-shaped For Options.
Box Color: White, Black, Grey, Or Customize Material: ABS Plastic, Retractable Spring, Stainless Steel Cable
Additional Function: Alarming Function, Stop Function Are For Options Operating Environment: There Are Dozens Of Ends Used To Connect Products To Different Uses

Cable Pulling Device  | RUIWOR 0Cable Pulling Device  | RUIWOR 1



Why choose Cable Pulling Device made in RUIWOR?



RUIWOR Technology focused on Cable Pulling Device 9 years, is the most complete variety of chinese Cable Pulling Device suppliers. About 5000 customers from 70 countrys are useing ruiwor's Cable Pulling Device.



3 times quality inspection before ex-factory is the guarantee of product quality.
Fast response within 24 hours is the guarantee of customer service.



Choose to buy Cable Pulling Device in RUIWOR Technology, is to choose a purchase process with save time / save money and no worry.



Company show:

Since 2009, RUIWOR Technology always have been focusing on Fine material selection, Attentively production, Efficient service.

Cable Pulling Device  | RUIWOR 2 Cable Pulling Device  | RUIWOR 3 Cable Pulling Device  | RUIWOR 4 Cable Pulling Device  | RUIWOR 5 Cable Pulling Device  | RUIWOR 6

Cable Pulling Device  | RUIWOR 7



Cable Pulling Device  | RUIWOR 8



Cable Pulling Device  | RUIWOR 9



Cable Pulling Device  | RUIWOR 10



Cable Pulling Device  | RUIWOR 11

Cable Pulling Device  | RUIWOR 12



How to choose Cable Pulling Device in RUIWOR?

RUIWOR offers a variety of Cable Pulling Device for retail and point-of-purchase displays. These products are also known as Anti-Theft Pull Box, Retractable Tether, Recoilers and cable retractors. They are
used for point of purchase security, theft deterrence, retail product positioning, equipment counterbalancing, wire harness positioning in electronic equipment,
product or parts feeding and signage support. RUIWOR supplies the following lines of
Cable Pulling Device.



Round Shaped Cable Pulling Device

Cable Pulling Device  | RUIWOR 13 Cable Pulling Device  | RUIWOR 14 Cable Pulling Device  | RUIWOR 15
RW5100 Cable Pulling Device RW5200 Cable Pulling Device RW5300 Cable Pulling Device
Size: 25.2*27.2*8.3mm
Retracting force: 1/3LB
Box Color: Black
Cable Color: Black/Gray
Attachment: All the ends show below
Cable Exit Point: only one
Cable length: 30CM
Diameter: 0.45-0.6 MM
Size: 31.5*34*11mm
Retracting force: 1/3LB
Box Color: Black
Cable Color: Black/Gray
Attachment: All the ends show below
Cable Exit Point: only one
Cable length: 80 CM
Diameter: 0.6mm-0.9 MM
Size: Ø41.5*12.2mm
Retracting force: 1/3LB
Box Color: Black
Cable Color: Black/Gray
Attachment: All the ends show below
Cable Exit Point: only one
Cable length: 60~90 CM
Diameter: 0.6-0.9 MM



Square Shaped Cable Pulling Device

Cable Pulling Device  | RUIWOR 16 Cable Pulling Device  | RUIWOR 17 Cable Pulling Device  | RUIWOR 18
RW4900 Cable Pulling Device RW1700 Cable Pulling Device RW5600 Cable Pulling Device
Size: 32*31.3*14.2mm
Retracting force: 1/3LB
Box Color: Black/White
Cable Color: Black/Gray
Attachment: All the ends show below
Cable Exit Point: only one
Cable length: 120CM/60CM
Diameter: 0.6-0.9MM
Size: 44.5*44.5*16mm
Retracting force: 1/3LB
Box Color: Black
Cable Color: Black/Gray
Attachment: All the ends show below
Cable Exit Point: only one
Cable length: 90~150 CM
Diameter: 0.9 MM
Size: 63.3*63.3*17.5mm
Retracting force: 1/3LB
Box Color: Black
Cable Color: Black/Gray
Attachment: All the ends show below
Cable Exit Point: only one
Cable length: 3M/2.5M/1.5M
Diameter: 0.9/1.2/1.5 MM



Cuboid Shaped Cable Pulling Device

Cable Pulling Device  | RUIWOR 19 Cable Pulling Device  | RUIWOR 20 Cable Pulling Device  | RUIWOR 21
RW0500 Cable Pulling Device RW0600 Cable Pulling Device RW1200 Cable Pulling Device
Size: 70x45x21mm
Weight: 43 g
Retracting force:
1.2LB,1/2LB,1/3LB, 1/4LB
Box Color: Black/White
Cable Color: Black/Gray
Attachment: All the ends show below
Cable Exit Point: A / B / C / D
Cable length: 96~140 cm
Diameter: 1.1 mm
Size: 70x45x21mm
Weight: 54 g
Retracting force:
1.2LB,1/2LB,1/3LB, 1/4LB
Box Color: Black/White
Cable Color: Black/Gray
Attachment: All the ends show below
Cable Exit Point: A / B / C
Cable length: 96~300 cm
Diameter: 1.1 mm
Size: 70x45x29mm
Weight: 98g
Retracting force:
1.2LB,1/2LB,1/3LB, 1/4LB
Box Color: Black/White
Cable Color: Black/Gray
Attachment: All the ends show below
Cable Exit Point: A / B / C / D
Cable length: 96~140 CM
Diameter: 1.2 MM



D-shaped / Drop-shaped / Heart-shaped Cable Pulling Device

Cable Pulling Device  | RUIWOR 22 Cable Pulling Device  | RUIWOR 23 Cable Pulling Device  | RUIWOR 24
RW0800 Cable Pulling Device RW1000 Cable Pulling Device RW5405 Cable Pulling Device
Size: 28.4x28.4x8.6mm
Weight: 9 g
Retracting force: 1/8LB
Box Color: Black
Cable Color: Black/Gray
Attachment: All the ends show below
Cable Exit Point: only one
Cable length: 93 cm
Diameter: 0.63 mm
Size: 50x32.5x15.5mm
Weight: 21 g
Retracting force: 1/3LB
Box Color: Black/White
Cable Color: Black/Gray
Attachment: All the ends show below
Cable Exit Point: A / B
Cable length: 96 cm
Diameter: 0.9 mm
Size: 54*45*12.3mm
Retracting force: 1/3LB
Box Color: White
Cable Color: Black/Gray
Attachment: All the ends show below
Cable Exit Point: only one
Cable length: 60~90 CM
Diameter: 0.6-0.9 MM



Following Cable Ends can work with any above Cable Pulling Device.

Cable Pulling Device  | RUIWOR 25

RW0000

Copper Head

Ball-shaped Casting

Gourd-shaped Casting

Cable Pulling Device  | RUIWOR 26

RW0001

Ring Terminal

Inner Diamension 3MM. 4MM, 5MM for option.

Cable Pulling Device  | RUIWOR 27

RW0002

Adhesive ABS Plate

Diamension 30MM



Cable Pulling Device  | RUIWOR 28

RW0003

Adhesive Metal Plate

35*22MM, 35*20MM for option.

Cable Pulling Device  | RUIWOR 29

RW0004

Sticky Metal Plate

Size: 45*19 MM



Cable Pulling Device  | RUIWOR 30

RW0005

Adjustable Loop End

5*6 MM (D*H), 9*9MM (D*H) for option.

Cable Pulling Device  | RUIWOR 31

RW0008

Sticky Flexible ABS Plate

Diamension 38MM



Cable Pulling Device  | RUIWOR 32

RW0009

Size Customizable Loop





Cable Pulling Device  | RUIWOR 33

RW0010

Adhesive ABS Plate

Size: 15*25 MM



Cable Pulling Device  | RUIWOR 34

RW0011

Flat Head Screw





Cable Pulling Device  | RUIWOR 35

RW0013

Adhesive ABS Plate

Diamension 30MM

Cable Pulling Device  | RUIWOR 36

RW0014

Demountable Key Ring



Cable Pulling Device  | RUIWOR 37

RW0016

Side Hole Hardware End



Cable Pulling Device  | RUIWOR 38

RW0017

Adhesive Magnetic Hold

Size: 40*25*22 MM

Cable Pulling Device  | RUIWOR 39

RW0019

Sticky Circular Metal Plate

Diamension 22MM

Cable Pulling Device  | RUIWOR 40

RW0021

Sticky Flexible Rubbe End

Cable Pulling Device  | RUIWOR 41

RW0022

Perforated Metal Plate

Cable Pulling Device  | RUIWOR 42

RW0024

Key Hook Cable End

Cable Pulling Device  | RUIWOR 43

RW0025

Adhesive Plastic Plate





If you are familiar with Ruiwor products, please inquire us with your quantity and the model number directly, we will give you a quotation within 24 hours.



Ortherwise, in order to you can efficiently purchase the suitable Cable Pulling Device with compertitive price, could you please let ruiwor know the details as following? then we will recommend the right porduct to you within 24 hours.

1 Your installation space

This determines what Cable Pulling Device series can be installed.

(our Smallest box size is 25*25*8.3MM, the Biggest box size is 63.4*63.4*17.5MM)

2 Cable length this mean what is the length you need the cable can be pulled out. (5 - 400CM for options)
3



Operating environment



This detemines which ends can connect your product, because our Cable Pulling Device can work with dozens of ends used to connect products to different uses. if you can send some picture about your product, that would be great helpfull to recommend the right Cable Pulling Device for you.
4 Cable Diameter 0.45 -2.0MM for options
5 Cable Color Black/ Transparent nylon cover the stainless steel cable
6 Available Retracting forces 0.1LB - 3LB for options
7 Box Color White, Black, Grey, or Customize
8 Box Shape Round,Square,Cuboid,D-shaped, Drop-shaped,Heart-shaped for options.
9 additional function alarming function,stop function



Some hot sale Cable Pulling Device will be listed as following, you can click the picture for more details.

Cable Pulling Device  | RUIWOR 44 Cable Pulling Device  | RUIWOR 45 Cable Pulling Device  | RUIWOR 46 Cable Pulling Device  | RUIWOR 47 Cable Pulling Device  | RUIWOR 48
Cable Pulling Device  | RUIWOR 49 Cable Pulling Device  | RUIWOR 50 Cable Pulling Device  | RUIWOR 51 Cable Pulling Device  | RUIWOR 52 Cable Pulling Device  | RUIWOR 53
Cable Pulling Device  | RUIWOR 54 Cable Pulling Device  | RUIWOR 55 Cable Pulling Device  | RUIWOR 56 Cable Pulling Device  | RUIWOR 57 Cable Pulling Device  | RUIWOR 58
Cable Pulling Device  | RUIWOR 59 Cable Pulling Device  | RUIWOR 60 Cable Pulling Device  | RUIWOR 61 Cable Pulling Device  | RUIWOR 62 Cable Pulling Device  | RUIWOR 63
Cable Pulling Device  | RUIWOR 64 Cable Pulling Device  | RUIWOR 65 Cable Pulling Device  | RUIWOR 66 Cable Pulling Device  | RUIWOR 67 Cable Pulling Device  | RUIWOR 68
Cable Pulling Device  | RUIWOR 69 Cable Pulling Device  | RUIWOR 70 Cable Pulling Device  | RUIWOR 71 Cable Pulling Device  | RUIWOR 72 Cable Pulling Device  | RUIWOR 73
Cable Pulling Device  | RUIWOR 74 Cable Pulling Device  | RUIWOR 75 Cable Pulling Device  | RUIWOR 76 Cable Pulling Device  | RUIWOR 77 Cable Pulling Device  | RUIWOR 78
Cable Pulling Device  | RUIWOR 79 Cable Pulling Device  | RUIWOR 80 Cable Pulling Device  | RUIWOR 81 Cable Pulling Device  | RUIWOR 82 Cable Pulling Device  | RUIWOR 83
Cable Pulling Device  | RUIWOR 84 Cable Pulling Device  | RUIWOR 85 Cable Pulling Device  | RUIWOR 86 Cable Pulling Device  | RUIWOR 87 Cable Pulling Device  | RUIWOR 88
Cable Pulling Device  | RUIWOR 89 Cable Pulling Device  | RUIWOR 90 Cable Pulling Device  | RUIWOR 91 Cable Pulling Device  | RUIWOR 92 Cable Pulling Device  | RUIWOR 93
Cable Pulling Device  | RUIWOR 94 Cable Pulling Device  | RUIWOR 95 Cable Pulling Device  | RUIWOR 96 Cable Pulling Device  | RUIWOR 97 Cable Pulling Device  | RUIWOR 98
Cable Pulling Device  | RUIWOR 99 Cable Pulling Device  | RUIWOR 100 Cable Pulling Device  | RUIWOR 101 Cable Pulling Device  | RUIWOR 102 Cable Pulling Device  | RUIWOR 103
Cable Pulling Device  | RUIWOR 104 Cable Pulling Device  | RUIWOR 105 Cable Pulling Device  | RUIWOR 106 Cable Pulling Device  | RUIWOR 107 Cable Pulling Device  | RUIWOR 108
Cable Pulling Device  | RUIWOR 109 Cable Pulling Device  | RUIWOR 110 Cable Pulling Device  | RUIWOR 111 Cable Pulling Device  | RUIWOR 112 Cable Pulling Device  | RUIWOR 113
Cable Pulling Device  | RUIWOR 114 Cable Pulling Device  | RUIWOR 115 Cable Pulling Device  | RUIWOR 116 Cable Pulling Device  | RUIWOR 117 Cable Pulling Device  | RUIWOR 118
Cable Pulling Device  | RUIWOR 119 Cable Pulling Device  | RUIWOR 120 Cable Pulling Device  | RUIWOR 121 Cable Pulling Device  | RUIWOR 122 Cable Pulling Device  | RUIWOR 123
Cable Pulling Device  | RUIWOR 124 Cable Pulling Device  | RUIWOR 125 Cable Pulling Device  | RUIWOR 126 Cable Pulling Device  | RUIWOR 127 Cable Pulling Device  | RUIWOR 128



How to purchase Cable Pulling Device in RUIWOR?



RUIWOR Makes it Easy...
Customized
Cable Pulling Device that you design. It's easy to accurately and precisely order just the right Cable Pulling Device model, Cable Pulling Device color, cable end,
retracting force and cable length you desire.
Design the
Cable Pulling Device that specifically meets your merchandise needs.



Here's How it Works...
Simply follow the chart below and specify the Quantity,
Cable Pulling Device Model, Cable End Model, Cable Pulling Device Color, Spring Retracting force, Cable Length,
Cable Color and Cable Exit Point, Follow the Example:

QTY(pcs) Cable Pulling Device
Model
Cable End
Model

Cable Pulling Device

Color

Spring Retracting
force (LB)
Cable
Length(MM)

Cable

Color

Cable Exit
Point
500 RW1000 RW0001 Black 1/3 960 Black B

This means the above order is 1000 pcs RW1001 Cable Pulling Devicex (Black Box, 1/3 LB Retracting force, 960mm Nylon Coated Black Cable and B Cable Exit Point).

Cable Pulling Device  | RUIWOR 129

RW1001 Cable Pulling Device



Contact RUIWOR freely if you don't see the Cable Pulling Device you need, then we will help you determine which is the best one suit your security plans.





Packaging & Shipping



Packaging Detail:

Each goods will be packed with opp bag, and then packed by 5 ply export carton. With strong enough cartons, tape used to bind the cartons, all cartons filled with packaging without empty space to ensure the cartons arrives customers without any goods lose.



Shipping Detail:

1. Cheapest freight cost is by sea to your nearest port (about 25 working days)

2. Cheaper freight cost is by air to your nearest airport (about 3-7 working days) or EMS

3. Convenient for customer but need pay higher freight cost by express economy service (DHL,UPS,FEDEX,TNT) to your door (about 4-7 working days)

4. The best Convenient and Efficient for customer but need pay highest freight cost by express via priority service (DHL,UPS,FEDEX,TNT) to your door (about 1-5 working days)



Our Services



We will always BE WITH YOU.

With 9 years experience in product sales and R & D, 24 hours online waiting for any customers every day even on weekends, highly efficient in emails reply to ensure offer our security display solutions to every customers.

We can do OEM, ODM, Urgent order, Small order, Sample order are wellcome.Payment is diversiform, easy to operate, safe. T/T, Western Union, Paypal will be accept.

RuiWor is the enterprise with innovative idea, strong research and development strength, can customize products for customers, Reliable quality assurance system, perfect after-sale service, agile management system, can provide first-class service.



Company Information

Nanchang Ruiwor Technology Co., LTD is a part of RuiWor Group, it focused on the export and Service on anti-theft display products, Ruiwor group is principally engaged in the design and production of anti-theft display products, insurance and equipment, electronic products, shelves, billboards, display boards, etc. Ruiwor products are widely apply to China Mobile Business Hall, China Unicom Business Hall, China Telecom Business Hall, Nokia, Lenovo, SONY, Apple specialty store, trademark clothing shop, glasses multiple shop, SU-NING, GOME, WALMART, etc.

Our factory area for anti-theft display products prodution is more than 2500 m², it has 4 series production lines, 58 Pipeline operators, 16 Quality controllers, 4 Managers. All their vision is to produce high-qualified products efficiently.

Cable Pulling Device  | RUIWOR 130



FAQ

1. How to order?

Cable Pulling Device  | RUIWOR 131

2. How about sample policy?

We will always offer free samples when we have the samples in stock, but freight cost should be paid by customers.

Some details can be discussed, so welcome to send us inquiries.



3. Which shipping way is available and how to track?

1. Cheapest freight cost is by sea to your nearest port (about 25 working days).

2. Cheaper freight cost is by air to your nearest airport (about 3-7 working days) or EMS.

3. Convenient for customer but need pay higher freight cost by express economy service (DHL,UPS,FEDEX,TNT) to your door (about 4-7 working days).

4. The best Convenient and Efficient for customer but need pay highest freight cost by express via priority service (DHL,UPS,FEDEX,TNT) to your door (about 1-5 working days).

When your order shipping out, we will provide you a tracking no. then you can know clearly the status of the goods.



4. Which payment way is workable?

PayPal (goods have stock, order value less than 500usd)

Western Union, MoneyGram

T/T also accept.



5. How to disassemble the 3M tape after display?

Use a card or buy a special tool from us, then wipe with clean rag Soaked with 75% alcohol.

Contact Details
NanChang Ruiwor Technology Co., Ltd.

Contact Person: Ms. Vivien

Tel: +86-15879006385

Fax: 86-0791-85951280

Send your inquiry directly to us (0 / 3000)
